Best sump pump and battery backup: the makers' 10 ft figures side by side, and the two failures no backup fixes
Zoeller rates the M53 at 34 GPM at 10 ft of head; Basement Watchdog rates the CITS-50 backup at 1,850 GPH at 10 ft. Neither helps if the check valve sticks.
- Verified
- Updated
- 11 min read
- 12 sources
Shop links on this page are affiliate links: a purchase may earn us a commission at no extra cost to you. Disclosure
OwnerSpec compares published manufacturer specifications, certification listings and sourced technical documents. Unless a page explicitly states otherwise, OwnerSpec has not laboratory-tested or used the products it compares. Editorial policy
Short answer
For a pit that runs every storm, the primary pick is the Zoeller M53: Zoeller’s FM2778 data sheet rates it at 34 GPM (2,040 GPH) at 10 ft of head, tested to UL 778, with a 3-year warranty. For the backup, the Basement Watchdog CITS-50 combo pairs a 1/2 HP primary rated 3,540 GPH at 10 ft with a battery pump rated 1,850 GPH at 10 ft and 48 hours at a 10 percent duty cycle on one battery, per Basement Watchdog’s product page. The runner-up backup is the Zoeller Aquanot Spin 508, rated 30 GPM (1,800 GPH) at 10 ft at 12.1 volts on its FM3165 sheet. Every figure on this page is the maker’s 10 ft number, not the 0 ft headline several Amazon titles print. Skip the whole category if your pit has not run in a year: find out why before buying. Skip water-powered backups on a well, because Liberty’s product page states it will not operate in an outage without municipal supply.
The picks
A pit that runs every storm and a lift under 15 ft
Zoeller M53 Mighty-Mate, 3/10 HP cast iron
Zoeller FM2778: 43 GPM at 5 ft, 34 GPM at 10 ft, 19 GPM at 15 ft, 19.25 ft shut-off head, 9.7 A at 115 V, 1-1/2 in NPT, tested to UL 778 and certified to CSA C22.2 No. 108, 3-year warranty
A high inflow pit or a long discharge run near 20 ft of head
Wayne CDU980E, 3/4 HP stainless and cast iron
Wayne's page: 5,245 GPH at 5 ft, 4,743 at 10 ft, 4,240 at 15 ft, 3,571 at 20 ft, vertical float, 1-1/2 in NPT, 8 ft cord, CSA agency approved, 5-year warranty
An occasional-run pit where the M53 is more pump than the lift needs
Wayne CDU790, 1/3 HP cast iron
Wayne's page: 4,600 GPH at 0 ft, 3,810 at 5 ft, 3,060 at 10 ft, vertical float, 1-1/2 in NPT, 8 ft cord, UL agency approved, 3-year warranty
Wants primary and backup pre-plumbed in one drop-in unit
Basement Watchdog Big Combo CONNECT CITS-50
Basement Watchdog's page: 1/2 HP primary 3,540 GPH at 10 ft, backup 1,850 GPH at 10 ft, 48 h on one battery at a 10 percent duty cycle, 96 h with two, dual micro-reed floats on both pumps, CSA main pump, cUL floats, controller and charger, 2-year warranty
Adding a backup to an existing primary and wants the honest battery curve
Zoeller Aquanot Spin 508 battery backup (508-0005)
Zoeller FM3165: 30 GPM at 10 ft at 12.1 V, 22 ft shut-off, 5.5 h continuous; product page adds 48+ h at a 10 percent duty cycle; Group 27, 29 or 31 battery with 175 minute reserve minimum, 3-year warranty
A cheaper backup for a 16 in or larger basin with modest inflow
Wayne ESP25n 12 V battery backup
Wayne's page: 2,700 GPH at 0 ft, 2,100 at 5 ft, 1,500 at 10 ft, 660 at 15 ft, up to 10,000 gallons on one charge, 1-1/2 in NPT, audible alarm; battery sold separately and its size is not printed on the page
Municipal water at 30 psi or more and no room for a battery
Liberty Pumps SumpJet SJ10, water powered
Liberty manual 5824000: 2 gallons removed per 1 gallon used, 20 to 100 psi inlet, 30 psi recommended minimum, 750 GPH at 8 ft lift on 40 psi, no battery; needs the backflow device your code names
If the primary pump has not cycled in twelve months, this page is not for you yet: a backup for a pit that never fills is a battery you replace before it runs, so time the pit with the sump pump size calculator first.
How was this shortlist built?
Every figure is a manufacturer’s published specification, read on 2026-09-24 from the document named beside it. Nothing was installed or run by this site. Listings were shortlisted from current Amazon listings, kept or rejected on the published spec, and confirmed in stock the same day.
Primary pumps were compared on flow at 10 ft of head, switch type, construction, cord and listing. Backups on flow at 10 ft on battery, runtime at the maker’s duty cycle and battery type. The water-powered unit on supply pressure, water used per gallon removed and backflow requirement.
The 10 ft column is the honest one. Zoeller’s FM3165 sheet warns that some makers publish DC pump data to marine industry standards that “can reflect a performance of 40% - 80% higher than actual battery powered performance”. Wayne’s ESP25n page prints 2,700 GPH at 0 ft and 1,500 GPH at 10 ft; the Amazon title carries the first number.
How do the units compare on paper?
Manufacturer figures. “Not published” means the cited page prints no value.
| Unit | Type | Flow at 10 ft of head | Switch | Construction | Listing published | Warranty |
|---|---|---|---|---|---|---|
| Zoeller M53 | Primary, 3/10 HP, 115 V | 34 GPM (2,040 GPH), 19.25 ft shut-off | Integral float, snap action | Cast iron housing, plastic impeller | Tested to UL 778, certified to CSA C22.2 No. 108 | 3 years |
| Wayne CDU980E | Primary, 3/4 HP, 120 V | 4,743 GPH | Vertical float, 9 in on, 4 in off | Stainless steel and cast iron | CSA agency approved | 5 years |
| Wayne CDU790 | Primary, 1/3 HP, 120 V | 3,060 GPH | Vertical float, 9 in on, 4 in off | Epoxy-coated cast iron | UL agency approved | 3 years |
| Basement Watchdog CITS-50 | Primary 1/2 HP plus 12 V backup | Primary 3,540 GPH, backup 1,850 GPH | Dual micro-reed floats on both pumps | Cast iron primary | CSA main pump; cUL floats, controller, charger | 2 years, 4 with battery registration |
| Zoeller Aquanot Spin 508 | 12 V backup | 30 GPM (1,800 GPH) at 12.1 V, 22 ft shut-off | Vertical float | Non-corrodible DC pump, aluminium seal pocket | CSA mark on the sheet, no standard number printed | 3 years |
| Wayne ESP25n | 12 V backup | 1,500 GPH | Not published on the page | Not published on the page | Not published | Not published on the page |
| Liberty SumpJet SJ10 | Water powered backup | 750 GPH at 8 ft on 40 psi; 558 GPH at 12 ft | Float operated valve | ABS | Internal check valve certified to ASME A112.18.3 and A112.18.1/CSA B125.1 | 3 years |
Zoeller M53: buy it or skip it?
Buy it if the pit runs every storm and the lift is under 15 ft. Zoeller’s FM2778 sheet prints 43 GPM at 5 ft, 34 GPM at 10 ft and 19 GPM at 15 ft, a 19.25 ft shut-off head, 9.7 A at 115 V, a 1-1/2 in NPT discharge and a cast iron motor and pump housing. It is tested to UL 778 and certified to CSA C22.2 No. 108, and the automatic model ships with a 9 ft cord.
The flaw is the curve: 34 GPM at 10 ft becomes 19 GPM at 15 ft, so a long horizontal run or a deep basement pushes it to the bottom of its range.
Skip it if the timed inflow is above about 2,000 GPH at your head. That is CDU980E territory.
Wayne CDU980E: buy it or skip it?
Buy it if the inflow is high or the head is near 20 ft. Wayne’s product page prints 5,245 GPH at 5 ft, 4,743 at 10 ft, 4,240 at 15 ft and 3,571 at 20 ft, a 3/4 HP oil-filled motor, an integrated vertical float with a 9 in on and 4 in off level, stainless steel and cast iron construction, an 8 ft cord, CSA agency approval and a 5-year warranty.
The flaw is that Wayne names CSA and no standard number for this unit, and UL and no standard number for the CDU790 . Zoeller prints both. For an occasional-run pit with a short lift, the CDU790 at 3,060 GPH at 10 ft is the cheaper Wayne.
Skip it if the basin is small: a 3/4 HP pump in a shallow pit short-cycles.
Basement Watchdog CITS-50: buy it or skip it?
Buy it if you want primary and backup already plumbed together. Basement Watchdog’s page rates the 1/2 HP primary at 4,400 GPH at 0 ft and 3,540 GPH at 10 ft, and the backup at 2,600 GPH at 0 ft and 1,850 GPH at 10 ft. It states 48 hours on one battery at a 10 percent duty cycle and 96 hours with two, dual micro-reed float switches on both pumps, a CSA listing on the main pump and cUL on the floats, controller and charger. The recommended battery is the BW-27AGM, sold separately.
The flaw is the duty cycle. Ten percent means six minutes an hour, and Basement Watchdog adds “runtimes may vary based on water flow”.
Skip it if the existing primary is sound: buy only the backup half and keep the pump you know.
Zoeller Aquanot Spin 508: buy it or skip it?
Buy it if you are adding a backup to a good primary and want a curve measured on a battery. Zoeller’s FM3165 sheet prints 39 GPM at 5 ft, 30 GPM at 10 ft, 20 GPM at 15 ft and 6 GPM at 20 ft at 12.1 volts, a 22 ft shut-off head, about 5.5 hours of continuous pumping, and a battery case that fits Group 27, 29 and 31 batteries. Zoeller’s product page adds 48 plus hours at a 10 percent duty cycle. Zoeller’s minimum is a deep-cycle Group 27 with 175 minutes of reserve capacity.
The flaw is voltage. Zoeller’s product page states approximately 34 GPM at 10 ft at 12.7 volts; the data sheet curve is drawn at 12.1 volts and gives 30 GPM, the figure printed here. Zoeller also says not to install it above 20 ft of total dynamic head.
Skip it if your basin is under Zoeller’s 16 in by 22 in minimum.
Wayne ESP25n: buy it or skip it?
Buy it if the inflow is modest and the basin is 16 in or larger. Wayne’s page prints 2,700 GPH at 0 ft, 2,100 at 5 ft, 1,500 at 10 ft and 660 at 15 ft, up to 10,000 gallons on a single charge, a 1-1/2 in NPT discharge and a battery case with an LED display and audible alarm.
The flaw is what Wayne does not print. The ESP25n page names no battery size, no runtime in hours, no listing and no warranty term, and the 10,000 gallon figure has no stated head or battery behind it.
Skip it if the lift is over 10 ft: at 15 ft it is rated at 660 GPH, less than half the CITS-50 backup.
Liberty SumpJet: buy it or skip it?
Buy it if the house is on municipal water and there is no room or appetite for a battery. Liberty’s manual states the SumpJet removes 2 gallons of sump water per 1 gallon of supply water, accepts 20 to 100 psi inlet, recommends at least 30 psi ahead of the backflow device, and needs no discharge check valve because it ships with a foot valve. Its table gives 750 GPH at 8 ft of lift and 558 GPH at 12 ft on 40 psi.
The flaw is the code. The same manual says sump water is non-potable and that “additional backflow protection must be provided by the installer to meet the requirements of the local plumbing code or the requirements of the local water authority”, and that under the Uniform Plumbing Code and in Michigan a reduced pressure zone device is required. Basepump’s page lists ASSE 1024, 1012 and 1001 devices and names Illinois, Wisconsin, Minnesota, Ohio and Indiana. Codes are adopted locally and vary, and an RP/RPZ lowers the supply pressure the pump sees.
Skip it on a well. Liberty states plainly that with a well pump the SJ10 will not operate during a power outage.
Time the pit before you buy a backup
Do not buy a backup until you know the inflow at your head. Time the rise in the basin with the sump pump size calculator: under about 1,500 GPH at 10 ft any backup here keeps up, and above it only the CITS-50 or the Aquanot Spin 508 does. If the pit never rises, the money belongs in a leak detector, not a pump.
What goes wrong?
The check valve sticks. Zoeller’s FM2676 sheet lists a stuck check valve as a cause of a pump that “starts and stops too often” and of one that “operates but delivers little or no” water. A backup pushing against the same stuck valve fails the same way. Zoeller also requires an approximately 3/16 in vent hole below the check valve so the pump does not air lock.
The discharge line freezes. Neither pump can push through ice. Liberty’s manual tells the installer to remove the foot valve poppet where freezing is a risk so water returns to the basin. Insulate and grade the exterior run; the frozen pipes guide covers the house side.
The battery is dead when the power goes. Zoeller’s FM2676 says to inspect and test the system at least every three months.
The outlet is wrong. Zoeller requires a 3-prong grounded receptacle wired to the National Electrical Code and says the ground pin must never be removed. A new circuit is electrician and permit work.
Frequently asked questions
Why does the Amazon title say 2,700 GPH when the page says 1,500?
Both are Wayne's numbers for the ESP25n. Wayne's product page prints 2,700 GPH at 0 ft of head, 2,100 at 5 ft, 1,500 at 10 ft and 660 at 15 ft. A sump pump lifts water, so the 0 ft figure describes a pump with no pipe on it. Compare every pump at the head your pit actually has, which for most basements is the 10 ft column.
How long will a battery backup sump pump actually run?
Only as long as the maker's stated duty cycle holds. Basement Watchdog rates the CITS-50 backup at 48 hours on one battery at a 10 percent duty cycle, and Zoeller rates the Aquanot Spin 508 at 5.5 hours of continuous pumping or 48 plus hours at 10 percent. A pit filling fast enough to run the pump continuously drains the battery in hours, not days.
Does a water-powered backup need a backflow preventer?
Liberty's SumpJet manual says sump water is non-potable and that additional backflow protection must be provided by the installer to meet the local plumbing code or water authority, naming a reduced pressure zone device under the Uniform Plumbing Code and in Michigan. Basepump's page names ASSE 1024, 1012 and 1001 devices. Codes are adopted locally and vary, so ask the water authority.
Will a battery backup help if the discharge line freezes?
No. A frozen or blocked line stops the backup exactly as it stops the primary, because neither can push water out. Liberty's SumpJet manual tells the installer to remove the foot valve poppet where freezing is a risk so water can flow back into the basin. The fix is the discharge line, not a second pump.
Do I need a check valve, and can it cause a failure?
Zoeller's installation sheet FM2676 says to install a check valve and a union in the discharge line, and to drill an approximately 3/16 in vent hole below the check valve so the pump does not air lock. Its troubleshooting table lists a stuck check valve as a cause of short cycling and of a pump that runs but delivers little water.
Fact sheet and how to cite this page
- Answer
- The primary pick is the Zoeller M53, rated on Zoeller’s FM2778 sheet at 34 GPM at 10 ft of head and tested to UL 778. The backup pick is the Basement Watchdog CITS-50 combo, whose backup pump Basement Watchdog rates at 1,850 GPH at 10 ft and 48 hours at a 10 percent duty cycle on one battery. Every figure is the maker’s 10 ft number, not the 0 ft headline.
- Comparison basis
- Manufacturer-published flow at 10 ft of head, switch type, construction, cord and listing for primary pumps; flow at 10 ft on battery, runtime and battery type for backups; supply pressure, water use ratio and backflow requirement for the water-powered unit.
- Assumptions
- The pit sees water every season, so a backup has something to back up
- Discharge is 1-1/2 in pipe and total dynamic head is at or under 15 ft, which is where the 10 ft column is the honest comparison point
- A water-powered backup is only considered where municipal supply is continuous, since Liberty’s SJ10 product page states the SumpJet will not operate in an outage on a well
- Method
- OwnerSpec compared manufacturer data sheets, manuals and product pages read on 2026-09-24 and confirmed each listing in stock the same day; it did not install, run or test any pump, and it prints the 10 ft column rather than the 0 ft headline.
- Primary source
- Zoeller Pump Company, Technical Data Sheet FM2778, Mighty-Mate Series Models 53/55/57/59 (PDF) (manufacturer or vendor document)
- Facts verified
- Last updated
- Cite as
- OwnerSpec, "Best sump pump and battery backup: the makers' 10 ft figures side by side, and the two failures no backup fixes", https://ownerspec.com/plumbing/reviews/best-sump-pump-and-battery-backup/, facts verified 24 September 2026.
